20 Foot Dry Box

Maximum Payload: 39,600 Lbs

Cubic Capacity: 1,170 Cubic Feet

Measures

Inside

Door Opening

Length

19' 4"

-

Width:

92.5"

92.0"

Height

94.0"

89.2"

40 Foot Dry Box . . Standard.

Maximum Payload: 59,000 Lbs

Cubic Capacity: 2,348 Cubic Feet

Measures

Inside

Door Opening

Length

39' 5"

-

Width:

92.0"

91.5"

Height

93.0"

89.0"

40 Foot Dry Box . High Cube

Maximum Payload: 57,120 Lbs

Cubic Capacity: 2,680 Cubic Feet

Measures

Inside

Door Opening

Length

39' 5"

-

Width:

92.0"

92.0"

Height

105.0"

101.0"

Notes:

Dimensions and Maximum Payload will vary slightly depending on Manufacturer and construction style of container.

Maximum Payload refers to the unit's capability and does not reflect local limitations, such as road and/or rail weight limits and port lifting capabilities.
